详细说明：
| 型号 | ZMRHL-2 | ZMRHL-3 | ZMRHL-4 | |
| 结构尺寸 | 电缆芯数 | 2 | 3 | 4 |
| 电缆外径（mm） | 10 | 11 | 12 | |
| 电缆重量（kg/km） | ＜250 | ＜300 | ＜350 | |
| 机械性能 | 弯曲半径（mm） | 70 | 80 | 90 |
| 电气性能 | 直流电阻（Ω/m） | ＜0.026 | ||
| 绝缘电阻（MΩ•km） | 1000 | |||
| 耐电压（V） | 1000 | |||
| 工作频率(kHz) | 20 | |||
| 衰减（db/m） | ＜1 | |||
| 串音衰减（db） | ── | ── | 70 | |
| 环境性能 | 工作温度（℃） | -20～85 | ||
| 水密性能（MPa横向） | 4.4 | |||
| 耐海水环境 | 适用 | |||
| 规格 | 导体规格 (根数/直径) | 近似密度公斤/KM | 标称外径/下限mm | 外径上限mm |
| 0.5*2C | 64 | 0.1 | 42.3 | 5.8 | 6.1 |
| 0.5*3C | 64 | 0.1 | 53.5 | 6.1 | 6.4 |
| 0.5*4C | 64 | 0.1 | 66.1 | 6.6 | 6.9 |
| 0.5*5C | 64 | 0.1 | 79.9 | 7.3 | 7.6 |
| 0.5*6C | 64 | 0.1 | 93.5 | 7.9 | 8.2 |
| 0.5*7C | 64 | 0.1 | 107.2 | 8.5 | 8.8 |
| 0.5*8C | 64 | 0.1 | 122.7 | 9.3 | 9.6 |
| 0.5*9C | 64 | 0.1 | 136.9 | 9.8 | 10.1 |
| 0.5*10C | 64 | 0.1 | 150.6 | 10.4 | 11.0 |
| 0.5*11C | 64 | 0.1 | 172 | 12.0 | 12.6 |
| 0.5*12C | 64 | 0.1 | 181.4 | 12.0 | 12.6 |
| 0.5*13C | 64 | 0.1 | 190.7 | 12.0 | 12.6 |
| 0.5*14C | 64 | 0.1 | 211.3 | 13.1 | 13.7 |
| 0.5*15C | 64 | 0.1 | 220.7 | 13.1 | 13.7 |
| 0.5*16C | 64 | 0.1 | 230.3 | 13.2 | 13.8 |
| 0.5*17C | 64 | 0.1 | 252 | 14.4 | 15.0 |
| 0.5*18C | 64 | 0.1 | 261.4 | 14.4 | 15.0 |
| 0.5*19C | 64 | 0.1 | 270.7 | 14.4 | 15.0 |
| 0.5*20C | 64 | 0.1 | 281.2 | 14.5 | 15.1 |
| 0.5*21C | 64 | 0.1 | 290.6 | 14.5 | 15.1 |
| 0.5*22C | 64 | 0.1 | 300 | 14.5 | 15.1 |
| 0.5*23C | 64 | 0.1 | 324.5 | 15.8 | 16.8 |
| 0.5*24C | 64 | 0.1 | 333.9 | 15.8 | 16.8 |
| 0.75*2C | 96 | 0.1 | 52 | 6.4 | 6.7 |
| 0.75*3C | 96 | 0.1 | 66.7 | 6.7 | 7.0 |
| 0.75*4C | 96 | 0.1 | 82.9 | 7.3 | 7.6 |
| 0.75*5C | 96 | 0.1 | 99.8 | 7.9 | 8.2 |
| 0.75*6C | 96 | 0.1 | 117.2 | 8.6 | 8.9 |
| 0.75*7C | 96 | 0.1 | 134.8 | 9.2 | 9.5 |
| 0.75*8C | 96 | 0.1 | 154.5 | 10.1 | 10.7 |
| 0.75*9C | 96 | 0.1 | 172.7 | 10.8 | 11.4 |
| 0.75*10C | 96 | 0.1 | 190.4 | 11.3 | 11.9 |
| 0.75*11C | 96 | 0.1 | 217.3 | 13.1 | 13.7 |
| 0.75*12C | 96 | 0.1 | 229.7 | 13.1 | 13.7 |
| 0.75*13C | 96 | 0.1 | 242.2 | 13.1 | 13.7 |
| 0.75*14C | 96 | 0.1 | 268.1 | 14.4 | 15.0 |
| 0.75*15C | 96 | 0.1 | 280.6 | 14.4 | 15.0 |
| 0.75*16C | 96 | 0.1 | 293.3 | 14.5 | 15.1 |
| 0.75*17C | 96 | 0.1 | 320.6 | 15.8 | 16.8 |
| 0.75*18C | 96 | 0.1 | 333.1 | 15.8 | 16.8 |
| 0.75*19C | 96 | 0.1 | 345.6 | 15.8 | 16.8 |
| 0.75*20C | 96 | 0.1 | 359.4 | 15.9 | 16.9 |
| 0.75*21C | 96 | 0.1 | 371.8 | 15.9 | 16.9 |
| 0.75*22C | 96 | 0.1 | 384.3 | 15.9 | 16.9 |
| 0.75*23C | 96 | 0.1 | 415.1 | 17.4 | 18.4 |
| 0.75*24C | 96 | 0.1 | 427.6 | 17.4 | 18.4 |
| 0.75*25C | 96 | 0.1 | 440 | 17.4 | 18.4 |
| 1.0*2C | 126 | 0.1 | 61.8 | 6.8 | 7.1 |
| 1.0*3C | 126 | 0.1 | 80.1 | 7.2 | 7.5 |
| 1.0*4C | 126 | 0.1 | 100.4 | 7.8 | 8.1 |
| 1.0*5C | 126 | 0.1 | 121.4 | 8.5 | 8.8 |
| 1.0*6C | 126 | 0.1 | 142.9 | 9.3 | 9.6 |
| 1.0*7C | 126 | 0.1 | 164.8 | 10.0 | 10.6 |
| 1.0*8C | 126 | 0.1 | 189.1 | 11.0 | 11.6 |
| 1.0*9C | 126 | 0.1 | 211.7 | 11.7 | 12.3 |
| 1.0*10C | 126 | 0.1 | 233.6 | 12.3 | 12.9 |
| 1.0*11C | 126 | 0.1 | 266.4 | 14.0 | 14.6 |
| 1.0*12C | 126 | 0.1 | 282.2 | 14.0 | 14.6 |
| 1.0*13C | 126 | 0.1 | 298.1 | 14.0 | 14.6 |
| 1.0*14C | 126 | 0.1 | 329.8 | 15.4 | 16.4 |
| 1.0*15C | 126 | 0.1 | 345.6 | 15.4 | 16.4 |
| 1.0*16C | 126 | 0.1 | 361.8 | 15.4 | 16.4 |
| 1.0*17C | 126 | 0.1 | 395.2 | 16.9 | 17.9 |
| 1.0*18C | 126 | 0.1 | 411.1 | 16.9 | 17.9 |
| 1.0*19C | 126 | 0.1 | 426.9 | 16.9 | 17.9 |
| 1.0*20C | 126 | 0.1 | 444.4 | 17.0 | 18.0 |
